Heavy-duty connectors, also known as HDC heavy-duty connectors, aviation plugs, are widely used in construction machinery, textile machinery, packaging and printing machinery, tobacco machinery, robots, rail transit, hot runners, electricity, automation, etc. that require electrical and signal connections In the device.
Two levers at the bottom part of the housing
o Secure locking ensured by four locking points
o Minimal space requirements and high locking force
o Ideal for laterally arranged connectors
Two levers on the hood
o Secure locking ensured by four locking points
o Minimal space requirements and high locking forces
o Ideal for laterally arranged connectors and surface-mounted housings with caps
One lever at the bottom part of the housing
o Two locking points along the longitudinal axis
o Easy to access even with cable entering laterally
o Cap on the upper part of the housing can be locked
Screw / bayonet locking system
o Actuated using a hexagon wrench or screwdriver
o Vibration-proof connections with outstanding sealing effect
o Easy to access even with cable entering laterally
o Prevents accidental or unauthorized opening
Hood Link locking system
o A resistant elastomer element connects and seals (IP65) hood and housing
o Ideal for quick and easy (flying) cable-to-cable connections
o Resistant to oils and gases; absorbing external mechanical forces
| Material | zinc die-cast |
| Colour | brushed nickel |
| Locking element | |
| ---Lever type | metal elastic pressing |
| ---Material | stainless steel |
| Hoods/Housing sealing | NBR |
| Limiting temperatures | -40℃...+125℃ |
| Flammability acc.to UL 94 | V0 |
| Degree of protection acc.to EN 60529 for coupled connector | IP65 |
