SM140
SMICO
2-4X(25-120)mm²
NFC 33-042; EN 50-483
400000/month
UV resistant glass fibre reinforced polymer
Availability: | |
---|---|
General Description:
The SMICO suspension clamps are designed to hang LV-ABC lines with insulated neutral messengers. The neutral messenger is fixed by an adjustable grip device. A movable link allows longitudinal and transversal movement of the clamp body.
Suspension Clamps are also available without bracket and with a fuse link. These suspension clamps are fixed to a pole with a pig tail hook or bracket.
Used for the installation and suspension of LV-ABC cables to poles with standard hook attachment.For straight lines and angles up to 30 ° 4X(25-120mm2) and 60 ° 4X(25-50).Thanks to the integrated constrution,no extra parts are needed for the installation .The body is made of corrosion proof aluminium and the inserts of weather resistant plastic .
Light duty clamp for the installation and suspension of 4-core LV ABC cables to poles with standard hook attachment . For straight Lines and angle up to 30°
For the installation and suspension of 4-core LV-ABC cables to poles with standard hook attachment.For straight lines and angles up to 90 °
Model | Conductor Range (mm2) |
SM130 | 2-4X(25-50) ≤60°/ 2-4X(25-50) ≤30° |
SM140 | 2-4X(25-120) ≤30° |
SM136 | 2-4X(25-120) ≤90° |
