Code: NX2003253
Name: Circuit breaker
Pole Mounted Circuit Breaker D265T (Middle Pole) with Digital Trip Unit

Description: The protection and management of MV / LV transformers in rural areas require the use of specific Circuit Breakers adapted to significant load imbalances and thus guarantee the total use of the installed power even in unbalanced conditions. These devices (4 poles - 3 protected) use air-break technology with chambers with metal partitions to cut the arc.
Benefits: Transformer protection (50 kVA, 100 kVA or 160 kVA) more compact and easier to use than a fused solution
When the Circuit Breaker is closed, a spark gap limits the rise in potential of the LV neutral from the earth, for a value exceeding 10 kV
When the Circuit Breaker is open, an electrical connection is done between the neutral of the transformer and the groundContact us to define your needs (number of feeders, fixing support, type of rod assembly, Trip Unit type, Load Indicator option, etc.)
  • D265T

  • SMICO

  • NX2003253

  • 50 - 150mm²

  • 50 - 150mm²

  • HN 63-S-11

  • 100000 pcs/year

  • 0.44KV

Rated current::
Rated short-circuit breaking capacity::
Rated short-circuit making current::
Rated short-time withstand current (1s): :
Rated power-frequency withstand voltage (50 Hz - 1min)::
Lightning impulse withstand level of voltage (1.2/50)::
Availability:

1

LV Pole mounted circuit breakers

The protection and management of MV / LV transformers in rural areas require the use of specific Circuit Breakers adapted to significant load imbalances and thus guarantee the total use of the installed power even in unbalanced conditions. These devices (4 poles - 3 protected) use air-break technology with chambers with metal partitions to cut the arc.


Benefits
1. Transformer protection (50 kVA, 100 kVA or 160 kVA) more compact and easier to use than a fused solution
2. When the Circuit Breaker is closed, a spark gap limits the rise in potential of the LV neutral from the earth, for a value exceeding 10 kV
3. When the Circuit Breaker is open, an electrical connection is done between the neutral of the transformer and the ground

4. Contact us to define your needs (number of feeders, fixing support, type of rod assembly, Trip Unit type, Load Indicator option, etc.)



Code NX2003253
Name Circuit breaker

Pole Mounted Circuit Breaker D265T (Middle Pole) with Digital Trip Unit
Standards: HN 63-S-11
Electrical values
Rated Voltage (Ur): 0.44 kV
Rated current: 265 A
Rated short-circuit breaking capacity: 6.4 kA
Rated short-circuit making current: 11.7 kA
Rated short-time withstand current (1s): 6.4 kA/s
Rated power-frequency withstand voltage (50 Hz-1min): 10 kV
Lightning impulse withstand level of voltage (1.2/50): 20 kV
Features
Degree of protection: IP31
Number of outputs: 2
Conductor size: 50 - 150mm²
Temperatures
Operating temperature: -25 ... 50 °C
Storage temperature: -25 ... 70 °C
Dimensions
Length: 400 mm
Width: 370 mm
Height: 550 mm
Weight: 19 kg
